Chemical Resistant Conveyor Belt

Rubber Conveyor Belt

Good elasticity,easy to through,low elongation.The rubber covers which made of chemical resistant materials have excellent anti-chemical corrosiveness and good physical properties.

Share To:

Inquiry Now

Product Details
Inquiry Now
You May Like

Product Details

Application：

Suitable for conveying corrosive materials in chemical factories,cement plant,fertilizer plants,paper mills,mining industry,etc.

Technical Data:

Physical property of cover rubber under hot air accelerated aging test(test condition:50℃*96h).

Class	Solution	Concentration	Covered Condition	The Change Rate Before And After Covered
				Volume Expansivity	Strength Change Rate
A1	(HCI)	18%	50℃x96h	≥10%	≤10%
A2	(H2SO4)	50%	50℃x96h	≥10%	≤10%
A3	(NaOH)	48%	50℃x96h	＞10%	＜10%

ITEM	Breaking Strength(Mpa)	Elongation At Break(%)	Abrasion(mm3)	Hardness(Shore)
Performance before aging	≥14.0	≥400	≤250	60±5
Performance after aging	≥12.0	≥350	-	60±5

Note: When the thickness of the cover rubber is 0.8mm 1.6mm,the sample thickness can be the maximum cut length,the tensile strength and elongation at break are allowed to be 15% lower than those in the table.
